EXFO FTB-5230S Optical Spectrum Analyzer for FTB 200 v2 - Manual (Page 473)

Referencia de instrucciones SCPI
OSA 467
Product-Specific Commands—Description
MINimum allows to set the instrument to the
smallest supported value.
MAXimum allows to set the instrument to the
greatest supported value.
The parameter corresponds to a valid channel setup index to select. The channel index cannot be zero.The CALCulate[1..n][:WDM]:CHANnel:COUNt? query can be used to determine valid index range.Example(s)CALC:WDM:CHAN:DEL:ALLCALC:WDM:CHAN:DEF "C_001",1525.000 NMCALC:WDM:CHAN:NSEL 1CALC:WDM:CHAN:SEL? Returns "C_001"See Also:CALCulate[1..n][:WDM]:CHANnel:COUNt?:CALCulate[1..n][:WDM]:CHANnel[:DEFine]:CALCulate[1..n][:WDM]:CHANnel:NSELect?:CALCulate[1..n][:WDM]:CHANnel:SELect:CALCulate[1..n][:WDM]:DATA:CHANnel:NSELect:CALCulate[1..n][:WDM]:CHANnel:NSELect Pages: 1 … 471 472 473 474 475 … 659 wrong Brand wrong Model non readable This manual is related to the following products: FTB -5240S/5240BP Optical Spectrum Analyzer for FTB 500 (NS-1434) See also other documents in the category EXFO Measuring instruments: ADSL2+ (124 pages) ADSL2+ (267 pages) ADSL2+ (275 pages) ARU-100 HPNA Test Probe (26 pages) ARU-100 HPNA Test Software Option for DSL/IP Tests (3 pages) AXS-100 Series OTDR (155 pages) AXS-200 SharpTESTER (70 pages) AXS-200/610 Copper Test Module (152 pages) AXS-200/650 IP Triple-Play Test Set (91 pages) AXS-200/850 Ethernet Test Set (262 pages) CableSHARK P3 VF/DSL Cable Qualifier (321 pages) DC0091A (3 pages) ELS-500 Light Source (45 pages) EOT Series (2 pages) EPM-ELS-50 (206 pages) ETS-1000 (173 pages) ETS-1000G (195 pages) ETS-1000L (47 pages) EXpert IP Test Tools (62 pages) EXpert IPTV Test Tools (FTB-1 / 2 Pro) (82 pages) EXpert IPTV Test Tools (FTB-200v2) (82 pages) EXpert VoIP Test Tools (107 pages) FIP-400 Fiber Inspection Probe and ConnectorMax (78 pages) FIP-400B Fiber Inspection Probe Multifiber (2 pages) FIP-400B Fiber Inspection Probe and ConnectorMax2 (111 pages) FIP-425B/435B Fiber Inspection Probe and ConnectorMax2 Mobile (103 pages) FLS-110 Optical Polarized Source (18 pages) FLS-300 Light Source (40 pages) FLS-5800 CD/PMD Analyzer Source (106 pages) FLS-5800 CD/PMD Analyzer Source (98 pages) FLS-5800 (6 pages) FLS-600 Light Source (79 pages) FOA Compatibility (3 pages) FOT-5200 Coarse Spectrum Analyzer (47 pages) FOT-930 Multifunction Loss Tester (111 pages) FTB -5240S/5240BP Optical Spectrum Analyzer for FTB 500 (NS-1434) (537 pages) FTB-5230S Optical Spectrum Analyzer for FTB 200 v2 (251 pages) FTB -5240S/5240BP Optical Spectrum Analyzer (638 pages) FTB-1 (234 pages) FTB-2 Pro (6 pages) FTB-2 Pro (443 pages) FTB-200 v2 Compact Modular Platform (222 pages) FTB-2200 for FTB-200 v2 (41 pages) FTB-3930 MultiTest (101 pages) Sitemap
channel setup index to select. The channel index
cannot be zero.
The CALCulate[1..n][:WDM]:CHANnel:COUNt?
query can be used to determine valid index
range.
Example(s) CALC:WDM:CHAN:DEL:ALL
CALC:WDM:CHAN:DEF "C_001",1525.000 NM
CALC:WDM:CHAN:NSEL 1
CALC:WDM:CHAN:SEL? Returns "C_001"
See Also :CALCulate[1..n][:WDM]:CHANnel:COUNt?
:CALCulate[1..n][:WDM]:CHANnel[:DEFine]
:CALCulate[1..n][:WDM]:CHANnel:NSELect?
:CALCulate[1..n][:WDM]:CHANnel:SELect
:CALCulate[1..n][:WDM]:DATA:CHANnel:NSELec
t
:CALCulate[1..n][:WDM]:CHANnel:
NSELect
