Chapter 4 BIOS Setup
46 Reference Manual ReadyBoard 910
• H/W Monitor
 CPU Temperature : +XX Degree C
 System Temperature : +XX Degree C
 CPU Fan Speed : XXXX RPM
 SYS Fan Speed: : XXXX RPM
 Vcore : +X.XXX V
 Vccp : +X.XX V
 Vcc : +X.XX V
 +5.0V : +X.XX V
 +12V : +XX.XX V
 VTR : +X.XX V
 Vbat : +X.XX V
• GPIO Configuration
 GPIO 1 Setting [GP0; GPI]
• GPO 1 Level [High; Low]
 GPIO 2 Setting [GP0; GPI]
• GPO 2 Level [High; Low]
 GPIO 3 Setting [GP0; GPI]
• GPO 3 Level [High; Low]
 GPIO 4 Setting [GP0; GPI]
• GPO 4 Level [High; Low]
 GPIO 5 Setting [GP0; GPI]
 GPIO 6 Setting [GP0; GPI]
 GPIO 7 Setting [GP0; GPI]
 GPIO 8 Setting [GP0; GPI]
• Serial Port Console Redirection
 COM0
• Console Redirection [Disabled; Enabled]
• Console Redirection Settings (When Console Redirection for this Port is Enabled)
- Terminal Type [VT100; VT100+; VT-UTF8; ANSI]
- Bits per second [9600; 19200; 38400; 57600; 115200]
- Data Bits [7; 8]
- Parity [None; Even; Odd; Mark; Space]
- Stop Bits [1; 2]
- Flow Control [None; Hardware RTS/CTS]
- VT-UTF8 Combo Key Support [Disabled; Enabled]
- Recorder Mode [Disabled; Enabled]
- Resolution 100x31 [Disabled; Enabled]
- Legacy OS Redirection Resolution [80x24; 80x25]
-Putty KeyPad [VT100; LINUX; XTERMR6; SCO; ESCN; VT400]
