Chapter 2 Product Overview
ReadyBoard 910 Reference Manual 17
Environmental Specifications
Table 2-5 provides the most efficient operating and storage temperature ranges required for this board.
Thermal/Cooling Requirements
The ReadyBoard 910 is designed to operate at its maximum CPU speed and requires a thermal solution to
cool the CPU, PCH, and voltage regulators. ADLINK offers two optional cooling solutions. (See Table 2-6
for descriptions of cooling options.)
Physical Specifications
Table 2-7 lists the physical dimensions of the board, and Figures 2-9 and 2-10 show the dimensions of the I/
O panel and top-side views of the board.
Table 2-7. Weight and Footprint Dimensions
Table 2-5. Environmental Requirements
Parameter Conditions
Temperature
Operating
–20°C to +70°C (–4°F to +158°F)
Extended (Optional) –40°C to +85°C (–40°F to +185°F)
Storage –55°C to +85°C (–67°F to +185°F)
Humidity
Operating
5% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, non-condensing
NOTE The overall system design must keep the ICs within their operating temperature
specifications.
Table 2-6. ADLINK Optional Cooling Solutions
Cooling Solution Description
Passive Heatsink
(without fan) Qualified to maintain optimal performance up to +70°C. (Note: Except
for the 3610QE and 2710QE CPUs, which require a fan.)
Active Heatsink
(with fan) Qualified to maintain optimal performance up to +80°C. (Note: The
3610QE and 2710QE CPUs require a fan and are qualified only for
+70°C.)
Item Dimension
NOTE Overall height is measured from the
upper board surface to the highest
permanent component (PCI-104
connector, CN2) on the upper board
surface. This measurement does not
include the cooling solutions available
for this board. The height of the active
heatsink (with fan) is 2.06" (52.30mm)
from the top surface of the board. The
height of the passive heatsink (without
fan) is 1.08" (27.43mm) from the top
surface of the board.
Weight 0.29kg. (0.65lbs. [without
DIMMs or heatsink])
Height (overall) 16.51mm (0.65")
Width 115mm (4.5")
Length 165mm (6.5")
Thickness 2.36mm (0.093")
