Chapter 3 Hardware
22 Reference Manual ReadyBoard 910
 Fan Interfaces
• Power and Sleep States
 Sleep States (ACPI)
 Wake-Up Activities
CPU
The ReadyBoard 910 supports six versions of the Intel
®
Core  i CPU—the 2nd Generation i3-2330E, i5-
2510E, and i7-2710QE, and 3rd Generation i3-3120ME, i5-3610ME, and i7-3610QE—operating at 2.2GHz,
2.5GHz, 2.1GHz, 2.4GHz, 2.7GHz, and 2.3GHz, respectively. The 3rd Generation Celeron B810, 1.6GHz is
also supported as a lower-cost model version. These CPUs integrate high-performance, 64-bit, x86 multi
Processor Cores with Memory Controllers and 3D Graphics Engines. This single chip is based on 32-nm
process technology for the 2nd Generation version and 22-nm for the 3rd Generation version and provides
an Intel Flexible Display Interface and a Direct Media Interface for high-speed connectivity to the PCH. The
CPUs also support Intel Hyper-Threading Technology (up to 4 cores, 8 threads) [except for the Celeron] and
up to 16 GB of DDR3 memory at 1066/1333 MHz for high overall performance.
Graphics
The 3rd Generation Core i CPUs provide a refresh of the seventh generation graphics core, which features a
substantial gain in performance and a decrease in power consumption. The next generation Intel Clear Video
HD Technology includes a collection of video playback and enhancement features that improve the end
user’s viewing experience including Encode/Transcode HD content, HD content playback, and superior
image quality. Other graphics features of the Core CPUs include support for DirectX 10.1, OpenGL3.0,
DirectX Video Acceleration (DXAV), Advanced Scheduler 2.0, 1.0, and XPDM.
Memory
The ReadyBoard 910 features dual-stacked SODIMM sockets for up to 16 GB of DDR3 memory. The CPU
provides an Integrated Memory Controller (IMC) with DDR3 protocols and two independent, 64-bit wide
channels each supporting one unbuffered, non-ECC SODIMM, employing up to two device ranks per
channel.
NOTE ADLINK Technology, Inc. supports only the features/options tested and listed in
this manual. The main integrated circuits (chips) used in the ReadyBoard 910
may provide more features or options than are listed for the ReadyBoard 910,
but some of these chip features/options are not supported on the board and may
not function as specified in the chip documentation.
This chapter does not include pinout tables for standard headers and connectors
such as PCI-104, Ethernet RJ45, SATA, USB, DB9 Serial, DB15 VGA, PS/2
Keyboard and Mouse, and PCIe Mini Card. See
Chapter 1 for hyperlinks to
specifications of these standard interfaces.
