Chapter 2 Product Overview
ReadyBoard 910 Reference Manual 9
Major Components
(ICs)
Table 2-1 lists the major Integrated Circuits (ICs) on the ReadyBoard 910, including a brief description of
each IC. Figure 2-4 shows the locations of the major ICs.
Table 2-1. Major Component Descriptions and Functions
Chip Type Mfg. Model Description Function
PCIe-to-PCI Bridge
(U5) Pericom
Semiconductor PI7C9X110BNBE PCIe-to-PCI
interface Migrates legacy PCI
interfaces
PCH (Platform
Controller Hub
[U15]) Intel BD82HM65 I/O Hub for
common user
interfaces Provides
Southbridge
interfaces and off
loads some
Northbridge
functions from CPU
TMDS Level Shifter
(U18) ASMEDIA
Technology ASM1442 TMDS level-shift
IC for DVI video Converts PCIe
differential input
from the PCH to
DVI differential
output
RS-485/422
Transceiver (U22) Linear
Technology LTC1334CG#PBF RS-485/422
Transceiver for
COM0 and
COM1 Transmits and
receives RS-485/
422 signals for
COM0 and COM1
Super I/O Hub
(U24) SMSC SCH3114I-NU Super I/O
controller Provides complete
legacy Super I/O
functionality
Solid State Drive
[SSD] - SATA (U25) Greenliant GLS85LS1004A Industrial-grade
soldered, solid-
state storage
module Provides solid-state
storage through
SATA (2.0) port 1
HD Audio CODEC
(U26) Realtek ALC262-VC2-GR Encoder and
decoder of audio
data for
transmission,
storage,
encryption,
playback, or
editing Provides four
channels of ADC
conversion and six
channels of DAC
display
CPU (U30) Intel Core i3-3120ME,
2.4GHz, 35W;
Core i5-3610ME,
2.7GHz, 35W;
Core i7-3610QE,
2.3GHz, 45W
Celeron B810,
1.6GHz, 35W;
Core i3-2330E,
2.2GHz, 35W;
Core i5-2510E,
2.5GHz, 35W;
Core i7-2710QE,
2.1GHz, 45W Central
Processing Unit
with 2 or 4
execution cores
and up to 8MB
L3 cache in an
rPGA988B
socket package Integrates Processor
Core and Graphics
Memory Controller
Hub
