Chapter 2

Product Overview

ReadyBoard 910

Reference Manual

19

Figure 2-10. Mechanical Overview (Top Side)

RB910_Mech_Dimen_b

6.10 (154.84mm)

6.30 (159.92mm)

5.55 (140.87mm)

2.52 (64.03mm)

2.03 (51.55mm)

0.00

0.20 (5.08mm)

0.02 (0.55mm)

(5.08mm) 0.20

(15.25mm) 0.60

(66.25mm) 2.60

(104.85mm) 4.13

(109.93mm) 4.33

0.00

0.00

2.50 (63.40mm)

4.76 (120.82mm)

5.70 (145.02mm)

5.52 (140.24mm)
