Section 3. Installation and Setup
ADV6600
Y S I
Environmental
Page 24
DOsat % Local Dissolved oxygen in % air saturation (set to 100 % at
calibration)
3-6.5. Advanced Menu Features
From the Sonde Main menu select 4-Advanced to display the sensor calibration constants,
additional setup options, and sensor coefficients/constants as shown below. The parameters listed
will depend on the sensors installed and enabled.
Select 1-Cal constants to display the calibration constants. Note that values only appear for the
enabled sensors. The following table provides the default value, operating range, and comments
relative to the calibration constants. Error messages will appear during calibration if values are
outside the indicated operating range unless the designation is “not checked”.
Parameter Default Operating Range Comments
Cond 5 4 to 6 Traditional cell constant
DO Gain 1 0.5 to 2.0
ORP offset mV 0.0 -100 to 100
pH offset 0.0 -400 to 400
pH gain -5.0583 -6.07 to -4.22
NH
4
J 51.2 Not checked
NH
4
S 0.195 0.15 to 0.217
NH
4
A 1.092 Not checked
NO
3
J 99.5 Not checked
NO
3
S -0.195 -0.217 to -0.15
