DGC-2020 Human-Machine Interface

2-3

Permissions

Communications access through the front panel will not be granted if communications access is active
through the modem or USB. In this case, the front panel will alternately display REMOTE COMMS,
FRONT PANEL IS READ ONLY and the summary screen. Remote access must be ended before gaining
access through the front panel.

Summary Screen and Configurable Metering

The summary screen can be set to standard or scrolling. When set to standard, only the following are
displayed:

• VOLT

• AMP

• PH

• Hz

• OIL

• FUEL

• TEMP

• BATT

When the summary screen is set to scrolling, you can select/configure the metering values that are
displayed. Up to 20 values can be displayed and these values will scroll at a delay time specified by the
user. To select a standard or scrolling summary, navigate to the SETTINGS, GENERAL SETTINGS,
FRONT PANEL HMI screen and edit the SUMMARY VIEW. The SCROLL DELAY setting is also found on
this screen.

To select the scrolling values, navigate to the SETTINGS, GENERAL SETTINGS, FRONT PANEL HMI
screen and edit the CONFIGURABLE METERING. The following values may be selected by the user to
be placed in the scrolling summary:

• NONE (Removes a line from the scrolling list)

• BLANK (Shows nothing on this line)

• OIL

• TEMP

• BATT

• RPM

SRC

• FUEL

• RUN

HRS

• GEN

VAB

• GEN

VBC

• GEN

VCA

• GEN

VAN

• GEN

VBN

• GEN

VCN

• BUS

• GEN

KWH

• GEN

• KW

TOT

• KVA
