1-4
DGC-2020 General Information
9400200990 Rev B
1 Second Rating:
2 Aac
5 Aac Current Sensing
Continuous Rating:
0.1 to 5.0 Aac
1 Second Rating:
10 Aac
Voltage Sensing
Configuration:
Line-to-line or line-to-neutral
Range:
12 to 576 V rms, line-to-line
Frequency:
Style selectable, 50/60 Hz or 400 Hz
Frequency Range:
10 to 72 Hz for 50/60 style and 10 to 480 Hz for 400 Hz style
Burden:
1 VA
1 Second Rating:
720 V rms
Generator Sensing Terminals:
41 (A-phase)
39
(B-phase)
37
(C-phase)
35
(Neutral)
Bus Sensing Terminals:
45 (A-phase)
43
(B-phase)
Contact Sensing
Contact sensing inputs include 1 emergency stop input and 16 programmable inputs. The emergency
stop input accepts normally closed, dry contacts. All programmable inputs accept normally open, dry
contacts.
Terminals
Emergency Stop:
46, 47
Programmable
Input 1:
30, 2
Input 2:
29, 2
Input 3:
28, 2
Input 4:
27, 2
Input 5:
26, 2
Input 6:
25, 2
Input 7:
24, 2
Input 8:
23, 2
Input 9:
22, 2
Input 10:
21, 2
Input 11:
20, 2
Input 12:
19, 2
Input 13:
18, 2
Input 14:
17, 2
Input 15:
16, 2
Input 16:
15, 2
Engine System Inputs
∗ Stated accuracies are subject to the accuracy of the senders used.
Fuel Level Sensing
Resistance Range:
33 to 240 Ω nominal
Terminals:
9, 11 (sender common)
Coolant Temperature Sensing
Resistance Range:
62.6 to 637.5 Ω nominal
Terminals:
10, 11 (sender common)
Oil Pressure Sensing
Resistance Range:
34 to 240 Ω nominal
Terminals:
8, 11 (sender common)
