11.22. D-2012AS Console Case
Finish Side panels: MDF, paint, black, mat finish
Armrest: MDF, leather upholstery, black, mat finish
Decorative panels: Stainless steel, silver
Dimensions 505 (w) x 127.5 (h) x 333.4 (d) mm or 19.88" x 5.02" x 13.13" (assembled with
the D-2012C)
Weight 2.3 kg or 5.07 lb, 7.5 kg or 16.53 lb (assembled with the D-2012C)
11.21. D-2000CB CobraNet Interface Module
Network I/F CobraNet: 100 BASE-TX, PRIMARY/SECONDARY 2 system
RJ45 connector, Enables decentralized installation,
Audio transmission only
Connection cable: Category 5 or higher shielded twisted pair cable for LAN
(CAT5-STP or better)
To be connected via the specified switching hub
Note: This network should be completely independent of
the LAN.
Number of D-2008SP connection: Max. 4
Switching hub stage: Max. 7
Max extend distance: 100 m or 109.36 yd (connected via a switching hub)
Input 16 channels, 20 bit/24 bit
Output 16 channels, 20 bit/24 bit
Sampling Frequency 48 kHz
Finish Panel: Pre-coated steel plate
Dimensions 17 (w) x 80 (h) x 140 (d) mm or 0.67" x 3.15" x 5.51" (excluding projection)
Weight 100 g (0.22 lb)
Note: The design and specifications are subject to change without notice for improvement.
• Accessory
Machine screw M3 x 8 .............................................................. 1
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Machine screw M4 x 25 (with washer) ................................... 11
Machine screw M4 x 10 ............................................................ 4
Rubber foot ............................................................................... 4
