73
11.2. D-2012C Remote Console Unit
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Power cord (2 m or 6.56 ft) ....................................................... 1
Fader knob (Yellow)* ................................................................ 3
Fader knob (Red)* .................................................................... 3
Rack mounting screw 5 x 12 (with plane washer) .................... 4
Cable clamp .............................................................................. 1
Machine screw M3 x 6 .............................................................. 1
* Convenient for color coding to distinguish channels to which stereo link or group settings are assigned.
Model No. D-2012C CE D-2012C CE-AU/CN D-2012C KR D-2012C TW
Power Source 220 – 240 V AC, 220 – 240 V AC, 220 V AC, 100 – 120 V AC,
50/60 Hz 50 Hz 60 Hz 60 Hz
Power Consumption 18 W
Volume Adjustment 100 mm (3.94") motorized fader x 12, rotary encoder x 8
Line Input 1 channel (stereo), +10 dB* to –20 dB*, 10 kΩ, unbalanced, RCA jack
Headphone output Stereo, 100 mW + 100 mW (at 32 Ω load), standard stereo phone jack
Monitor Bus 1 stereo input, 1 stereo output
Connector:
RJ45 connector
Connection Cable: Shielded twisted pair (STP) Cat 5 or higher LAN
cable (data lines: 2 pairs)
Maximum Cable Distance: 100 m or 109.36 yd (between D-2012C and
D-2008SP)
LAN Network I/F: 1 channel, 10BASE-T- or 100BASE-TX-compatible
network (switching: automatic recognition), RJ45
connector, connection via a switching hub
Network Protocol: TCP/IP
Connection Cable: Category 5 or higher shielded twisted pair cable
for LAN (CAT5-STP or better)
Maximum Cable Distance: 100 m or 109.36 yd (between D-2012C and a
switching hub))
Control RS-232C: D-sub connector (9P), for maintenance use
Operating Temperature 5 to 40 °C (41 to 104 ºF)
Finish Panel: Surface treated steel sheet, laminated with
polycarbonate sheet, gray, mat finish
Rack mount bracket: Surface treated steel sheet, gray, mat finish
Dimensions 482 (w) x 266 (h) x 138 (d) mm (18.98" x 10.47" x 5.43")
Weight 6.6 kg (14.55 lb)
