Toa D-2000 Series Installation - Manual (Page 30)

30
D-2012C
Perforated pane
(with ventilation slots)
Notes
• To achieve sufficient ventilation, be sure to mount a perforated panel larger than 1U size* above the unit.
• Do not position the heat-generating component such as a power amplifier immediately below the D-2012C in
the rack. Also, keep such components away from each other so that the ambient temperature around the D-
2012C should not exceed +40 ºC. Failure to do so may shorten the product life.
* 1U size = 44.5 mm or 1.75" (standard size)
3.2.3. D-911
D-911
3.2.2. D-2012C
D-2012C
