74
11.3. D-911 VCA Fader Unit
Power Supply 5 V DC (supplied from the optional D-984VC)
Connector RJ45 connector x 8
Input Fader Control Input fader (100 mm or 3.94") x 12
Output Volume Control Output volume control x 8
Contact Control Illuminated switch x 8
Remote Output No-voltage make contact output (contact capacity: 30 V DC, 4 A)
Remote Switch Seesaw switch for activating the remote function of the power distributor
Finish Panel: Pre-coated steel plate, black (30 % gloss)
Dimensions 482.6 (w) x 177 (h) x 61.3 (d) mm (19" x 6.97" x 2.41") (excluding projection)
Weight 3 kg (6.61 lb)
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Fader knob (Red, Yellow)* ............................................... 3 each
Volume knob (Red)* ................................................................. 2
Rack mounting screw 5 x 12 (with plane washer) .................... 4
Rack mounting bracket (preinstalled on the unit) ..................... 2
* Convenient for color coding to distinguish channels to which stereo link or group settings are assigned.
Input 2 channels, Mic/Line changeable
Mic: –50/–36 dB*, 4.7 kΩ, electronically-balanced, XLR-3-31 type
Line: –10/+4 dB*, 10 kΩ, electronically-balanced, XLR-3-31 type
Phantom power supply (+15 V, can be used when set for the microphone)
Ground lift switch
A/D Converter 24 bits
Sampling Frequency 48 kHz
Frequency Response 20 Hz – 20 kHz, ±1 dB (+4 dB* input)
Dynamic Range Over 100 dB (IHF-A weighted) (+4 dB* input)
Total Harmonic Distortion Under 0.05 % (+4 dB* input)
Finish Panel: Pre-coated steel plate, black (30 % gloss)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm (1.38" x 4.7" x 7.02")
Weight 150 g (0.33 lb)
11.4. D-921F Microphone/Line Input Module
* 0 dB = 0.775 V
Note: The design and specifications are subject to change without notice for improvement.
