Model Number a
1
l
1
l
2
AI 1,5-8 BK
AI-TWIN 2 x 1,5-8 BK 6.6 (0.26)
a
2
3.6 (0.14)
14 (0.55)
16 (0.63) 2.3 (0.09)
8 (0.31)
8 (0.31)
a
3.4 (0.31)
Unit: mm (in)
b
1.8 (0.07)
Model Number a l 1 l 2
AI 0,34-8 TQ
AI 0,5-8 WH
2 (0.08)
Unit: mm (in)
2.5 (0.1)
12.5 (0.49)
14 (0.55)
8 (0.31)
8 (0.31)
b
0.8 (0.03)
1.1 (0.04)
35
4.3. Removable Terminal Plug Connection
Notes
• Avoid soldering stranded or shielded cable, as contact resistance may increase when the cable is tightened
and the solder is crushed, possibly resulting in an excessive rise in joint temperatures.
• When connecting 2 cables or a shielded cable to a single terminal,
use a ferrule terminal with an insulation sleeve to crimp the cables
because such cable conductors could become loose.
Recommended ferrule terminals for signal cables
(made by Phoenix Contact)
Recommended ferrule terminals for power supply cables
(made by Phoenix Contact)
Crimping tool: CRIMPFOX UD6-4 (made by Phoenix Contact)
Wiring procedures
Step 1. Wiring the supplied removable terminal plug.
1-1. Loosen the terminal screws to insert the wire.
1-2. Tighten the terminal screws.
Ensure that the wire does not break free when
pulled. If the wire does pull free, repeat the
connection procedure from the start.
Step 2. Insert the wired terminal plug into the
corresponding terminal block in the unit's rear
panel.
Note
Do not reverse Steps 1 and 2 above. Force is applied
to the connected receptacle pins while tightening the
terminal screw and they may be damaged, resulting in
bad connector contact.
Solid cable and stranded cable Shielded cable
7 mm*
(0.28'') (0.28'')
(0.59'')
7 mm*
15 mm
Terminal screw
Removable terminal plug
Slotted screwdriver
Tightens Loosens
Bit shape 3 mm
Tip
Recommended slotted screwdriver type:
Screwdriver with blade that is 3 mm (0.12'') in width
(0.12'')
Cable sheath to trim
Insulation sleeve
Contact section
Insulation sleeve
Contact section
a
l 2
a
1
a
2
l 1
l 2
l
1
b
b
* Expose 8 mm (0.31'') or more when using
the above ferrule terminal, and cut off an
extra conductor protruding from the sleeve.
