80
Contact Input COM + Terminals 1 – 8: Open voltage: 5 V DC, short-circuit: 5 mA,
10-pin removable terminal block
Preset Memory Any preset memory can be recalled.
Selection Control method: No-voltage make of over 100 ms or
no-voltage make single pulse of over 100 ms
Volume Volume can be turned UP or DOWN for any input and output channels.
Control system: 1 step variation for no-voltage make single pulse of over
100 ms
1 step continuous operation for every 70 ms for no-voltage
make of over 100 ms. Can be reset when at break.
Variable range: –∞ dB to +10 dB
Channel Any input/output channels can be turned ON and OFF.
Control method: No-voltage make of over 100 ms or
no-voltage make single pulse of over 100 ms
Stereo Selection Any stereo input can be selected.
Control method: No-voltage make of over 100 ms or
no-voltage make single pulse of over 100 ms
Contact Output COM + Terminals 1 – 8: No-voltage make contact input,
contact capacity: 24 V DC, 100 mA
10-pin removable terminal block
Finish Panel: Pre-coated steel plate, black (30 % gloss)
Dimensions 35 (w) x 119.5 (h) x 178.4 (d) mm (1.38" x 4.7" x 7.02")
Weight 125 g (0.28 lb)
Control
• Accessories
10-pin removable terminal plug (preinstalled on the unit) ......... 2
11.18. D-981 Remote Control Module
Note: The design and specifications are subject to change without notice for improvement.
