11. SPECIFICATIONS
11.1. D-2008SP Digital Mixing Processor Unit
Model No. D-2008SP CE D-2008SP CE-AU/CN D-2008SP KR D-2008SP CU D-2008SP TW
Power Source 220 – 240 V AC, 220 – 240 V AC, 220 V AC, 120 V AC, 100 – 120 V AC,
50/60 Hz 50 Hz 60 Hz 60 Hz 60 Hz
Power Consumption 76 W 78 W
Frequency Response 20 Hz – 20 kHz, ±1 dB (±4 dB* input)
Sampling Frequency 48 kHz
Input/Output Input: Max. 32 channels, modular construction (modules optional)
Output: Max. 32 channels, modular construction (modules optional)
Monitor bus: 1 stereo input, 1 stereo output
Connector: RJ45 connector
Connection cable: Shielded twisted pair (STP) Cat 5 or
higher LAN cable
(data lines: 2 pairs)
Maximum cable distance: 100 m or 109.36 yd (between
D-2008SP and D-2012C)
Headphones: 1 stereo
Feedback Suppression 12 filters (auto/dynamic), Max. 4 bus channels
Function
Auto Mixing Function
Ducker (auto muting), NOM attenuation
Auto Mixing Group 4 groups
Equalizer/Filter Parametric equalizer: 20 Hz – 20 kHz, ±15 dB, Q: 0.267 – 69.249
Filtering: High-pass filter
20 Hz – 20 kHz, 6 dB/oct, 12 dB/oct
Low pass filter 20 Hz – 20 kHz, 6 dB/oct, 12 dB/oct
Notch filter 20 Hz – 20 kHz, Q: 8.651 – 69.249
All-pass filter 20 Hz – 20 kHz, Q: 0.267 – 69.249
High shelving filter 6 Hz – 20 kHz, ±15 dB
Low shelving filter 20 – 500 Hz, ±15 dB
Horn equalizer 20 kHz, 0 to +18 dB (0.5 dB steps)
Crossover filter: 20 Hz – 20 kHz, 6 dB/oct, 12 dB/oct, 18 dB/oct, 24 dB/oct
Compressor (Compressor mode)
/Auto-Leveler Threshold: –20 to +20 dB (1 dB steps)
Ratio: 1:1, 1.1:1, 1.2:1, 1.3:1, 1.5:1, 1.7:1, 2:1, 2.3:1, 2.6:1,
3:1, 4:1, 5:1, 7:1, 8:1, 10:1, 12:1, 20:1, ∞:1
Attack time: 0.2 ms – 5 s
Release time: 10 ms – 5 s
Gain: –∞ to +10 dB
Knee Type: Hard knee, Soft knee 1, Soft knee 2
(Auto-leveler mode)
Target level: –20 to +20 dB (1 dB steps)
Maximum gain: 0 to +20 dB (1 dB steps)
Attack time:
10 ms – 10 s
Release time: 100 ms – 10 s
Output Delay Delay time: 0 – 1360 ms (0.021 ms steps)
Bus Delay Delay time: 0 – 677 ms (0.021 ms steps)
Matrix Input: Max. 34 (32 + 2) channels x 24 bus
Output: Max. 44 (24 + 4 + 16) bus x 32 channels
CobraNet Matrix Input: Max. 16 channels x 24 bus
Output: Max. 28 (24 + 4) bus x 16 channels
Crosspoint Gain –∞ to 0 dB (1 dB steps)
Preset Memory 32
Auxiliary Function Key lock function
Signal Processing
* 0 dB = 0.775 V
