6. Remote (activation) output terminals
Setting the Remote (activation) switch (3) to the
ON position closes the output.
7. VCA control module connection terminals
These terminals are used exclusively for the D-
984VC VCA Control module. Use an RJ45
connector for connection.
Note
Avoid connecting any other than the D-984VC to
these terminals.
6
7
[Rear]
