Chapter 5 - RMS Mapper
Start Mapping

RMS Mapper for the Legacy 6000

Software Version 2.00

The Center Vehicle soft-key. Press to center the vehicle in the map page.

Generate Object soft-key. Pressed to bring up a menu that allows you to set
up a map object to be mapped (see The Map Objects Soft-Key on page 5-13).

The Pan soft-key. Press to pan around in the map page, using the arrow keys.

Antenna Offset soft-key. Press to change the antenna offset.

Erase Object soft-key. Press to erase the last object or object vertex created.

Soft-key

Description

Table 5-6: Real time Soft-key Description
