1-4 Chapter 1 - System Introduction
Legacy 6000 Console
RMS -EXT for the Legacy 6000
Software Version 2.00
Legacy 6000 Console
The Legacy 6000 console runs RMS-EXT software and operates in a Windows CE environment
(Windows CE is a product of Microsoft); an extremely dependable and stable operating system.
Operation is intuitive, with on-screen menu choices and prompts. An on-board help menu is built
in. The heart of the Legacy console is an Intel processor operating at 206 Megahertz for maximum
efficiency. Other features of the Legacy 6000 console include:
Dimensions: 8.0" Wide x 7.7" High x 4.5" Deep (203 x 196 x 114 mm)
Weight: 2.3 lbs. (1.0 kg)
Enclosure: Sealed plastic; back lighted; tactile feed-back switches on front panel
Display: Color 5.7" diagonal (120 x 90 mm), transflective, QVGA with CCFL back lighting. Bright-
ness control via back light control over contrast using discreet switches.
Input/Output: CAN, Bosch 2.0B
Serial: RS 232 (2)
USB: (1)
TTL digital I/O: (10)
Memory: 64 Mbytes DRAM, 16Mbytes Flash
Microprocessor: 32-bit Intel StrongArm, SA 1110 with SA 1111 companion chip. 206 MHz.
Drives: PCMCIA type II, single slot
Operating System: Microsoft Windows CE 3.0
Power Requirement: 9 to 16 volts DC
Connector: Sealed, 31 pin Deutsch
GPS Receiver Compatibility: Compatible with any differentially corrected, submeter GPS
(DGPS) receiver that outputs NMEA 0183 at 2 to 5 Hz.
Alarm: Audible alarm
Other:
* Real-time clock with battery back-up
* Simple, yet versatile, RAM mounting bracket.
