RMS Mapper for the Legacy 6000

Software Version 2.00

Chapter 5 - RMS Mapper 5-5

Setting up a Job

Pressing the Mapper button in the RMS-EXT Main Launcher brings up the Job page (Figure 5-2).
You must have a PC card installed to create a job and store application and trajectory data.

Each Job created with a unique job id has an associated file folder named after the job id and
placed at the root of the inserted PC card. All data files associated with a job are stored in this
folder on the PC card.

There are three methods for entering/selecting a job: select an existing Job, create a job based on
an existing job, and create a new job.

Selecting an Existing Job

You can select an existing job from the Job page (Figure 5-2) using the Up and Down arrow keys.
An existing Job has an associated file folder located on the PC card. The name of the job folder is
the same as the job number.

Figure 5-2: The Job Page

Create a new Job

Soft-Key

Create a Job
Based on Another
Job Soft-Key.
