RMS Mapper for the Legacy 6000
Software Version 2.00
Chapter 5 - RMS Mapper 5-9
Mapper Launcher
Road Markers Setup
The Road Marker setup menu allows you to pre-define points and hazards, for easier access dur-
ing the real time mapping process. There is a unique object soft-key in the real-time Map page
(Figure 5-8) for each marker that you define in this setup menu.
Figure 5-6: The Road Markers Setup Page
Parameter Description
Marker # The type of marker being defined: Point, Hazard, and Not Used.
Name # The name of the marker defined above.
Table 5-3: Road Marker Setup Description
