2-6 Chapter 2 - Getting Started
Software Overview
RMS-EXT for the Legacy 6000
Software Version 2.00
next character space in the dialog box. Use the left and right arrow keys to move across the char-
acter spaces and edit existing entries.
If entering a numeric value, use the decimal point in the character set to set the number of digits to
the left and right of the decimal point, (E.G. 0.254, 1.00, 10.0, 100.463). This allows you to set the
required significant digits.
If a USB keyboard is connected to the Legacy 6000 console, you can type information directly into
the alpha/numeric dialog box.
Exiting a Data Entry Page
There are two ways to exit a data entry page: “Exit without saving changes” and “Save and exit”.
To exit the setup without saving changes press the Back Arrow button located at the top of the left
column. To exit and save any changes made, press the Forward Arrow at the top of the right col-
umn or the Enter key on the console. Either of these exit methods returns you to the setup menu
page that the data entry page was accessed from.
Figure 2-5: Example of Pick List Data Entry Page
Forward Arrow
Save & Exit Back Arrow
Exit & No Save
Setting description and help text window.
Name of Setup
Parameter
