4-20 Chapter 4 - RMS Map Manager
Printing Maps in Map Manager
RMS Office
Software Version 3.10
Printing Maps in Map Manager
Version 3.10 of RMS Map Manager brings improved printing capabilities. Pressing the print button
in the button bar, or selecting print from the file menu, brings up the Print Settings dialog (Figure 4-
17). You can control the look and layout of the printed map from this dialog. Some of the Print Set-
ting features are listed in Table 4-8
Setting Description
Portrait Displays the map in portrait mode.
Landscape Displays the map in landscape mode.
Show Preview Displays a preview of the printed map in the Map Manager Map View. This is
recommended.
Legend Text Add a Map title and additional text to the printed map. To add text, start typing
in the Legend text window.
Logo Include a company logo in the printed map. To add a logo, press the browse
button and select the logo image file.
Scale Bar Include a distance scale bar in the printed map.
Rate Bar Include a Rates legend in the printed map. The map view must contain an
(.RCD) file.
Target Bar Include a distance Application Target Rate legend in the printed map. The map
view must contain an (.ARM) file.
Table 4-8: Print Setting Descriptions
