TeeJet RMS Office - Manual (Page 111)

RMS Office
Software Version 3.10
Chapter 4 - RMS Map Manager 4-33
Shape File Conversion
Function Descriptions
Create Export Tem-
plates When checked, the program automatically generates an export template for
any Point, Polyline, or Polygon objects imported. This template is a reverse
image of the import template used for the object. The new template name
begins with the word “Export”, followed by the name of the import template. For
example, if you use ShpToPoint.tpl to import points, the export template is
named Export[ShpToPoint].tpl.
2D Radio Button When checked, the program loads all available 2D templates into the template
combo box. The templates are located in the bin\ template folder.
3D Radio Button When checked the program all available 3D templates into the template combo
box. The templates are located in the bin\ template folder.
Templates-Point Select the type of import conversion, by choosing a conversion template. This
template defines how to represent a point, in a shapefile, in an RMS data file.
Templates-Polylines Select the type of import conversion by choosing a conversion template. This
template defines how to represent an arc, in a shapefile, as a polyline in an
RMS data file.
Templates-Polygon Select the type of import conversion by choosing a conversion template. This
template defines how to represent a polygon, in a shapefile, in an RMS data
file.
Table 4-13: Import Dialog Description
