Chapter 4 - RMS Map Manager 4-9
The RMS Map Manager Tool Bar
The RMS Map Manager Tool Bar
The tool bar allows the manipulation of how you view the data in the window. Drawing tools are
accessed from the Tool bar, as well as zoom, pan, and measure. You can add, remove, and unload
layers from the view. The current or active layer is the layer that sits on top of all other layers. To
remove or unload a layer, make it the current layer and click on the remove current layer button.
Only the current layer can be removed.
All Map Manager Tool Bar buttons are described in Table 4-2.
Figure 4-6: The Map Manager Tool Bar
Button Description
New File (Layer) - creates a new file (layer) and places it at the current (top) layer in the
map view. A prompt asks for the new file name.
Open Existing File (Layer) - An Open File dialog allows the selection of an existing file
(Layer), in the top layer of the map view.
Save File (Layer) - save the current (top) layer in the map view.
Save All - save all files (layers) displayed in the map view.
Print - prints the current map view, with all visible layers.
Table 4-2: Map Manager Tool Bar Button Descriptions
New File (Layer)
Open Existing File
Remove Current Layer
Layers On/Off
Current (top) Layer File Saving Zoom to Extents
