Chapter 9: Using the web browser
TruVision NVR 21(S/P) User Manual 81
Figure 32: Example of a video image with text insertion
To set up text insertion:
1. Click the Configuration tab in the browser toolbar and then select 232 Serial Port .
2. Under Usage, select ProBridge .
3. In the submenu panel, select Text Insertion.
4. Check Enable Text Insertion .
5. Select the access device from the drop-down list.
6. Select the access mode. Only “ProBridge” is listed.
7. Under Start String, enter the desired transaction text, such as an ATM transaction
number.
8. Click Save to save the settings.
To search text insertion in recorded video:
1. In playback, check the By text check box.
2. In the keyword text box that appears, enter the text for which you want to search.
