Chapter 4: Operating instructions
TruVision NVR 21(S/P) User Manual
21
Task
Button
Button function
F2
Press to hide the control panel.
Pause mode
Direction
The left and right buttons are used to jump recorded video
forwards or backwards by one frame. The up and down buttons
are used to jump recorded video forwards or backwards by one
second.
PTZ control mode
Direction
Press to control the movement of the PTZ camera.
Zoom +/-
Press to zoom in and out.
Preset
Press Preset and a numeric button to call the specified preset.
Tour
Press Tour and a numeric button to call the specified shadow
tour.
Play
Press to do an auto tour.
Display
Press to delete a selected key point from the PTZ Setting >
More Settings> Tour > Key Point list.
F2
Press to stop all ongoing operations.
Menu navigation
Direction
Press to navigate between different fields and items in menus.
Menu
Enter/exit the main menu.
Enter
Press to confirm the selection in any of the menu modes.
Zoom +/-
Press Zoom + and – to switch between different tabs in a menu
screen.
Preset
Press to navigate in a text field, press to move the cursor to the
left.
Tour
Press to navigate in a text field, press to move the cursor to the
right.
F1
Press to exit the virtual keypad.
F1
Select all or deselect all options in a menu.
F2
Press to select or deselect an item.
Multiview mode
Display
Press to toggle through the various multiviews: full, quad, 1+5,
1+7, 9, and 16.
Calendar mode
Zoom +/-
Press Zoom+ and then the Up/Down buttons to scroll between
months. Use the Left/Right buttons to scroll between years.
Press Zoom+ again to quit the calendar mode.
Tour
Press Tour and then the Up/Down buttons to scroll between
months. Use the Left/Right buttons to scroll between years.
Press Tour again to quit calendar mode.
Menu
Press Menu and then Up/Down buttons to scroll between weeks.
Press Menu and then Left/Right buttons to scroll between days.
Search mode
Play
Play a selected video from the Event Search results.
Play a selected video from the Log Search results.
Play a selected video from the Normal Search results.
View a selected picture from the Picture Search results.
Play a selected video from the Bookmark Search results.
Play a selected video on the USB flash drive.
Holiday mode
Preset
Press to edit a holiday listed under Display Mode Setting >
