Chapter 5: Live view
TruVision NVR 21(S/P) User Manual 37
Submenu name Description
General tab
Alarm full screen
monitoring dwell time Set the length of time for which an alarm appears on the output
monitor before moving to the next camera during sequencing. Default
is 10 seconds.
To set up the display options:
1. Click the Display Mode Settings icon in the menu toolbar.
2. Select Layout > General .
3. Specify the desired settings for each of the menu options.
4. Click Apply to save the settings.
5. Click Back to return to live view.
Changing the camera sequence
The cameras are sequenced in numeric order by default. You can change the
sequence order of the cameras for all monitors.
You can switch the channel of a camera with that of another camera in the system. This
lets you, for example, have the images of camera 1 appear on channel 10, and the
images of camera 10 appear on channel 1. This feature is useful when you want to
watch the sequence of images from specific cameras so that they are next to each
other on-screen.
See Figure 16 below. Each video tile displays both the order of the camera in the
sequence and the camera number.
Figure 16: Camera layout and sequence screen
Multiview layout selection bar
Camera order in the sequence
Camera number selection
