Chapter 6: Controlling a PTZ camera
TruVision NVR 21(S/P) User Manual
45
Figure 21: PTZ configuration window
Table 16: Description of the PTZ configuration window
Item
Name
Description
1.
Save preset
Saves preset.
2.
Call preset
Calls up pre-existing preset.
3.
Shadow tour toolbar
Start recording the shadow tour.
Save the shadow tour.
Start the selected shadow tour.
Stop the selected shadow tour.
4.
Preset tour toolbar
Add a step to a selected preset tour.
Start the selected preset tour.
Stop the selected preset tour.
Delete all the preset tour steps.
Move the selected preset to an upper level.
Move the selected preset to a lower level.
To set up a preset:
1. From the menu toolbar, click
PTZ Settings
>
More Settings
.
2. Use the directional, zoom, focus and iris buttons to position the camera in the
desired preset location.
