Appendix D: KTD-405 keypad
TruVision NVR 21(S/P) User Manual 151
8. Press . The main menu appears.
Example 2: To modify a menu option using the keypad
1. In the main menu press and hold esc and then press the arrow buttons to navigate
to the desired menu icon (for example, Display Mode Settings).
2. Press esc and to go to setup menu.
3. Press Zoom + or Zoom - to scroll to the menu tab, More Settings .
4. When in the desired menu screen, press and hold esc and then press the arrow
buttons to navigate the cursor to the option, Menu Timeout .
5. Press to activate the dropdown menu.
6. Press and hold esc and then press the up/down arrow buttons to navigate to the
desired option.
7. Press to select the option.
8. Press and hold esc and then press the up/down arrow buttons to navigate to Apply.
Press to select it. Then navigate to Back to return to live view.
Instead of the arrow buttons, you can also use the joystick on the keyboard.
TVN 21(P) mapping to the KTD-405 keypad
Table 23: TVN 21(P) mapping to the KTD-405 keypad
Task Keypad action Further information
 Menu mode
Call up or exit menu In live view, press esc . To exit the menu: go to the Power
Manager menu and select Logout.
Move through the menus Press and hold esc and
then press the arrow
buttons or use the joystick.
Down , Up , Left ,
Right
Move between menu tabs Press Zoom + or Zoom - to
switch between menu tabs.
Navigate to a menu option Press and hold esc and
then press the arrow
buttons.
Down , Up , Left ,
Right
Select a character or menu
option Press Enter ( ). Note. If you press esc before pressing
Enter , you quit the menu without saving
any changes. It is the same as cancel.
Select the zone ID Press zone to connect the
keypad to the recorder and
enter the Zone ID.
