Chapter 5: Live view
TruVision NVR 21(S/P) User Manual 39
Option Description
Device name Define the recorder name. The default name is TVN 21.
Click the edit box and enter the new name from the soft keyboard.
Device address The device number to use for the recorder when programming the remote
control. The default value is 255.
Zone ID Each recorder in a daisy chain must have a unique zone ID so that it can be
controlled by a KTD-405 keypad.
The default value is 1.
VGA resolution Define the VGA resolution.
Select one of the options from the drop-down list and click Apply . The
selected resolution must be the same as that of the monitor.
HDMI resolution Define the HDMI resolution.
Select one of the options from the drop-down list and click Apply . The
selected resolution must be the same as that of the monitor.
Password required Define whether a login password is required.
Check the box to enable/disable and click Apply .
Enable wizard Define whether the wizard tool starts when the recorder is turned on.
Check the box to enable/disable and click Apply .
Display status icons Define whether the status icons are displayed.
Figure 18: Monitor Setup screen: More Settings
Table 13: Description of the Monitor Setup screen: More Settings
Option Description
Monitor standard The video standard used is auto detected but can be manually changed.
Modify the video standard used to PAL or NTSC and click Apply .
Output mode Define the desired output mode.
Select one of the options from the drop-down list: Standard, Bright, Soft, or
Vivid.
Monitor brightness Modify the video output brightness.
Adjust the scroll bar point to the desired level and click Apply .
Event hint Define whether the event hint icon appears on screen. See “Status
information” on page 29 for more information.
