TruVision NVR 21(S/P) User Manual 29
Chapter 5
Live view
Description of live view
Live view mode is the normal operating mode of the unit where you watch live images
from the cameras. The recorder automatically enters into live view mode once powered
up. On the viewer, you can see the current date and time, camera name, and whether a
recording is in progress.
Status information
Information on the system and camera status is displayed as icons on the main and
spot monitors. The camera status icons are shown for each camera. Each icon
represents information on a specific item. These icons include:
Table 6: Description of the on-screen status icons
Icon Description
Indicates a sensor alarm.
Indicates recording (such as constant recording, motion detection or alarm-
triggered recording).
Indicates a motion detection event.
Indicates a video loss event.
Indicates alarms and system notifications. Clicking the icon opens a screen that
lists the alarms and notifications.
Indicates manual recording.
More than one icon can be displayed at the same time.
The system status is displayed on the front panel by the status LEDs.
