Chapter 7: Playing back a recording
52 TruVision NVR 21(S/P) User Manual
Figure 22: Playback window
1. Playback viewer.
2. Camera panel. Select the cameras for
playback. Move the mouse over the area to
display the list of cameras available.
3. Calendar panel.
Blue: Current date
Green/Yellow/Red: Recordings available on the
recorder.
4. Playback control toolbar. See Figure 23.
The playback control toolbar
It is easy to manually control playback using the playback control toolbar. See
Figure 23 below.
Note: The control toolbar does not appear for instant playback.
Figure 23: Playback control toolbar (search playback example shown)
Description
1. Audio and video control toolbar:
/ Audio on/off.
/ Start/stop a video clip during playback. Sections of a recording can be saved to an
external storage device.
Add default bookmark
Add customized bookmark
Bookmark management.
Click to see the list of bookmarks and their times. They can be renamed or deleted.
