IC Realtime Flex Series: 32-CH High Performance H.264E 2U DVR User Manual
Page 49
39
In Encode interface, click snapshot button to input snapshot mode, size , quality and
frequency. See the interface on the left of Figure 4-17.
In FT P ( Main Menu- >Network->Networ k Setting) interface , please input upload interval. See
the interface in the middle of Figure 4-17.
In Schedule interface, please enable snapshot function. See interface on the right of Figure
Please refer to the following figure for detailed infor mation. See Figure 4-17.
Figure 4-17
4.5.2.2 Activation Snapshot
Please follow the steps listed below to enable the activation snapshot function. After you
enabled this function, system can snapshot when the corresponding alar m occurred.
In Encode interface, click snapshot button to input snapshot mode, size, quality and
frequency. See the interface on the left of Figure 4-18.
In FTP interface please input upload interval. See the interface in the middle of Figure
In Detect interface please enable snapshot function for specified channels (interface in
the middle of Figure 4-18). Or in alar m interface ( interface on the right of F igure 4-18)
please enable snapshot function for specified channels.
Please refer to the following figure for detailed infor mation. See Figure 4-18.
