IC Realtime Flex Series: 32-CH High Performance H.264E 2U DVR User Manual
Page 16
6
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
Front panel, USB mouse, remote control
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G.711A
Video monitor
Video Input
24-CH composite video input:
(NTSC/PAL) BNC (1.0V
B
P- P,
B
75Ω)
32-CH composite video input:
(NTSC/PAL) BNC (1.0V
B
P- P,
B
75Ω)
Video
Output
1-ch PAL/NTSC, BNC (1.0VP-
P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (50f/s), NTSC (60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4/8/9/16/25 windows
1/4/8/9/16/25/36 windows
Monitor
Touring
Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
Resolution
(PAL/NTSC
)
PAL/NTSC
Real-time monitor：
D1 704Ч576/704Ч480
Playback：
Each channel supports:: D1 704Ч576/704Ч480 , CIF 352Ч288/
352Ч240 , QCIF 176Ч144/176Ч120
Default resolution is 2CIF (25/30fps). Support D1and HD1(6/7fps)
Support dual streams: extra stream resolution CIF 352Ч288/ 352Ч240,
QCIF 176Ч144/176Ч120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
16-ch 200-2000mv
10KΩ(BNC)
