107
Figure 7-11
7.3.2.1 Direction key and 3D positioning key
In Figure 7-10, there are eight direction keys.
In the middle of the eight direction keys, there is a 3D intelligent positioning key.
Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the
mouse in the screen to adjust section size. It can realize PTZ automatically.
7.3.2.2 Speed
System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster than
speed 1.
7.3.2.3 Zoom/Focus/Iris
Here is a sheet for you reference.
Name Function
key Function Function
key Function
Zoom Near Far
Focus Near Far
Iris close Open
In Figure 7-11, click PTZ setup button you can see the following interface. See
X4 38H4 38H4 38H
Figure 7-12
X
.
You can click this icon to
display or hide the PTZ
control platform.
3D Intelligent Positioning
Key
