3
Audio
Compressio
n
G.711A
Video monitor
Video Input
24-CH composite video input:
(NTSC/PAL) BNC (1.0V
B
P- P,
B
75Ω)
32-CH composite video input:
(NTSC/PAL) BNC (1.0V
B
P- P,
B
75Ω)
Video
Output
1-ch PAL/NTSC, BNC (1.0VP-
P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
1-ch matrix output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition 1/4/8/9 /16/25windows 1/4/8/9 /16/25/36windows
Monitor
Touring Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
Resolution
(PAL/NTSC
)
PAL/NTSC
Real-time monitor：
D1 704Ч576/704Ч480
Playback：
Each channel supports: D1 704Ч576/704Ч480 , CIF 352Ч288/
352Ч240 , QCIF 176Ч144/176Ч120
Default resolution is 2CIF (25/30fps). Support D1and HD1(6/7fps)
Support dual streams: extra stream resolution CIF 352Ч288/ 352Ч240,
QCIF 176Ч144/176Ч120.
Quality 6-level image quality (Adjustable)
Privacy
mask Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust Adjust TV output zone suitable to anamorphic video.
Channel
Lock Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Color
Configuratio
n Hue, brightness, contrast, saturation and gain setup for each channel.
Audio Audio Input 4-ch 200-2000mv
10KΩ(BNC)
Audio
Output
1-ch audio output 200- 3000mv 5KΩ(BNC)
Bidirectional
Audio 1-ch audio talk input 200-3000mv 10K Ω (BNC)
1-ch audio talk output 200-3000mv 5K Ω (BNC)
Hard disk Hard Disk 4 built-in SATA port. Support 4 HDDs.
Hard Disk
Occupation Audio：G711 27.5MByte/h
Video：56-900MByte/h
