12
Assistant Fn
One-window monitor mode, click this button to display
assistant function: PTZ control and image color.
Backspace function: in numeral control or text control, press
it for 1.5seconds to delete the previous character before the
cursor.
In motion detection setup, working with Fn and direction
keys to realize setup.
In text mode, click it to switch between numeral, English
character(small/capitalized) and etc.
Realize other special functions.
Fast play

Various fast speeds and normal playback.
Play previous

In playback mode, playback the previous video
Reverse/Pau
se
 
In normal playback or pause mode, click this button to
reverse
playback
In reverse playback, click this button to pause playback.
Play Next

In playback mode, playback the next video
In menu setup, go to down ward of the dropdown list.
Play/Pause
 In normal playback click this button to pause playback
In pause mode, click this button to resume playback.
USB port To connect USB storage device, USB mouse.
Status
indication
light
Status
If there is Fn indication light, current status indication light is
null.
HDD
abnormal
indication
light
HDD
HDD error occurs or HDD capacity is below specified
threshold value, the light becomes red to alert you.
Remote
control
indication
light
ACT Remote control indication light
Power
indication
light
Power Power indication light
Record light 1-16
System is recording or not. It becomes on when system is
recording.
For this series product, the last 12 lights are null since there
is only four channels.
IR Receiver IR
It is to receive the signal from the remote control.
