Real-time monitor, Figure 7-6, Figure 7-7 – IC Realtime Flex Series: 32-CH High Performance H.264E 2U DVR User Manual
Page 114
104
Preview window switch. System support 1/4/8/9/16-window real-time preview. Please you
need to have the proper rights to implement preview operation. You can not preview if you
have no right to preview the either channel. See Figure 7-5. Please note this series device
does not support this function.
Figure 7-5
Figure 7-6
7.3.1 Real-time Monitor
In section 2, left click the channel name you want to view, you can see the corresponding video
in current window.
On the top left corner, you can view device IP, channel number, network monitor bit stream.
Figure 7-7
On the top right corer, there are six unction buttons. See
X
434H
1 2 3
Section1
Section 2
Section 3
Section 5
Section 4
