122
Please refer to the following sheet for detailed information.
Parameter Function
RS232 There are two options: COM 01 and keyboard.
Function
Console is to upgrade the program or debug via COM or
mini terminal software.
Keyboard: COM control protocol. You can use keyboard to
control DVR via COM.
Data Bit
The value ranges from 5 to 8.
Stop Bit
There are three options: 1/2.
Baud Bit You can select corresponding baud bit here.
Parity
There are five options: none/odd/even/space/mark.
System default setup is:
 Function: Console.
 Data bit: 8
 Stop bit: 1
 Baud bit: 115200
 Parity: None.
7.5.2.5 Network
Network interface is shown as in
X462H 462H 462H
Figure 7-37.
Figure 7-37
Please refer to the following sheet for detailed information.
