S.BUS Servo Description of function of each parameter
*There are a function which can be used according to the kind of servo, and an impossible function.
‡ ,'
Displays the ID of the servo whose parameters are to be read. It cannot be changed.
‡ &KDQQHO
Channel of the S.BUS system assigned to the servo. Always assign a channel before use.
‡ 5HYHUVH
The direction in which the servo rotates can be changed.
‡ 6HUYR W\SH
When “Retractable” is selected and the servo has been continuously stopped for 30 seconds, the dead band
expands and unnecessary hold current due to external force is eliminated. When a new control signal enters,
normal operation is resumed. When using the servo as a landing gear servo, select “Retractable”. Also adjust the
servo travel to match the landing gear movement range.
‡ 6RIW 6WDUW
Restricts operation in the specified direction the instant the power is turned on. By using this setting, the first initial
movement when the power is turned on slowly moves the servo to the specified position.
‡ 6WRS 0RGH
The state of the servo when the servo input signal is lost can be specified. The "Hold" mode setting holds the
servo in its last commanded position even if using AM or FM system.
‡ 6PRRWKHU
This function changes smoothness of the servo operation relative to stick movement changes. Smooth setting is
used for normal flight. Select the "OFF" mode when quick operation is necessary such as 3D.
‡ 1HXWUDO 2IIVHW
The neutral position can be changed. When the neutral offset is large value, the servo's range of travel is restricted
on one side.
‡ 6SHHG &RQWURO
Speeds can be matched by specifying the operating speed. The speed of multiple servos can be matched without
being affected by motor fluctuations. This is effective for load torques below the maximum torque.
However, note that the maximum speed will not be exceed what the servo is capable of even if the servos
operating voltage is increased.
‡ 'HDG EDQG
The dead band angle at stopping can be specified.
[Relationship between dead band set value and servo operation]
Small ĺ Dead band angle is small and the servo is immediately operated by a small signal change.
Large ĺ Dead band angle is large and the servo does not operate at small signal changes.
(Note) If the dead band angle is too small, the servo will operate continuously and the current consumption will
increase and the life of the servo will be shortened.
‡ 7UDYHO $GMXVW
The left and right travels centered about the neutral position can be set independently.
‡ %RRVW
The minimum current applied to the internal motor when starting the servo can be set. Since a small travel does
not start the motor, it essentially feels like the dead band was expanded. The motor can be immediately started by
adjusting the minimum current which can start the motor.
[Relationship between boost set value and servo operation]
Small ĺ Motor reacts to a minute current and operation becomes smooth.
Large ĺ Initial response improves and output torque increases. However, if the torque is too large, operation will
become rough.
