34
How to turn transmitter power ON/OFF
W h e n t u r n i n g o n t h e p o w e r, t h e T 1 4 S G
transmitter will begin emmiting RF automatically
DIWHU LW FRQ¿UPV WKH VXUURXQGLQJ 5) FRQGLWLRQV
The T14SG transmitter also offers the ability to
auto shut-down.
When turning on the power of the transmitter
1. Turn on the power switch of the transmitter.
7KH PHVVDJH &+(&. 5) &21',7,21 LV GLVSOD\HG IRU D
PRPHQW $W WKH VDPH WLPH WKH OHIW /(' PRQLWRU EOLQNV
2. Then, you will see the home screen and the
transmitter begins to emit radio waves.
7KH OHIW DQG ULJKW /(' PRQLWRUV ZLOO FKDQJH WR VROLG UHG
How to stop the transmitter
1. Turn off the power switch of the transmitter.
*The transmitter shuts down at once.
Low battery alarm and auto shut-down
When the battery voltage reaches 5.2V, an
DXGLEOH DODUP ZLOO VRXQG /DQG \RXU DLUFUDIW
immediately.
When the battery voltage reaches 3.9V, the
transmitter will be turned off automatically.
*If you do not operate the transmitter (or move a stick,
knob, switch or digital trim) for 30 minutes, the message
3/($6( 7851 2)) 32:(5 6:,7&+ LV GLVSOD\HG DQG
an audible alarm will sound.
Warning display at power ON (Airplane/
Helicopter)
:KHQ WKH WKURWWOH VWLFN GXULQJ 3RZHU 2Q LV DW
the high side (or over 1/3 stick) a warning will be
displayed.
*below 1/3 stick, the warning display goes off.
Registration of the user's name
If so desired, the T14SG transmitter can
indicate the owner's name.
User's name setup screen
1. Turn on the power of the transmitter.
*The home screen appears.
2. Lightly touch the SYS button twice rapidly
and the System menu appears.
3. Select [USER NAME] in the System menu and
touch the RTN button.
*The user name set up screen appears.
Input Box
*Current user name is displayed.
Changing the user name
1. Change the user name as described below:
[Moving cursor in input box]
6HOHFW >ł@ RU >ń@ DQG WRXFK WKH 571 EXWWRQ
[Deleting a character]
When [DELETE] is selected and the RTN button
is touched, the character immediately after
the cursor is deleted.
[Adding a character]
When a character is selected from the
character list and the RTN button is touched,
that character is added at the position
immediately after the cursor.
*A name of up to 10 characters long can be entered as the
user name. (A space is also counted as one character.)
2. At the end of input, select [ENTER] and tuoch
the RTN button. (To terminate input and
return to the original state, select [CANCEL]
and touch the RTN button.)
