PA05
Enabling of differential pressure switch
alarm
Not-
active
(0)
Not-active
(0)
Active (1)
Sec
CO-S
PA06
Delay of differential pressure switch alarm
10
0
999
Sec
CO-S
PA08
Signals differential pressure switch alarm
on alarm relay
No (0)
No (0)
Yes (1)
Sec
CO-S
Only if
PG02=0
PA09
Anti-freeze alarm active on hot water coil
Not-
active
(0)
Not-active
(0)
Active (1)
Sec
CO-S
PA10
Anti-freeze alarm delay on hot water coil
10
0
999
Sec
CO-S
PA12
Activates the heaters thermal switch alarm
Not-
active
(0)
Not-active
(0)
Active (1)
Sec
CO-S
Only if
PG02>=2
PA13
Signals heaters thermal overload alarm on
alarm relay
No (0)
No (0)
Yes (1)
CO-S
Only if
PG02=2
PA16
Enable supply high temperature alarm
from transducer
Not-
active
(0)
Not-active
(0)
Active (1)
CO-S
PA17
Supply high temperature alarm setpoint
85.0
PH01
PH02
°C
°F
CO-S
PA19
Supply high/low temperature alarms
differential
3.0
0.0
0.0
20.0
36.0
°C
°F
CO-S
PA20
High/low temperature alarms delay
10
0
999
Sec
CO-S
PA22
Expansion alarm delay
5
0
999
Sec
CO-S
PA24
RTC alarm enabling
Active
(1)
Not-active
(0)
Active (1)
-
CO-S
PA26
Probes alarms signals delay
10
0
240
Sec
CO-S
PA51
Type of alarm fire/smoke
0: Not-active
1: Off by allarm
2: Forcing 1
3: Forcing 2
1
0
3
-
CO-S
VARIOUS PARAMETERS
PH11
Board Modbus address
1
1
247
-
CO-V
PH12
Communication Baud Rate for the board
(0=1200, 1=2400, 2=4800, 3=9600,
4=19200)
3
0
4
-
CO-V
PH13
ModBus Parity (0=none, 1=Odd, 2=Even)
2
0
2
-
CO-V
PH14
Stop Bit ModBus (0=1bit, 1=2bit)
0
0
1
-
CO-V
PH40
Enable supply temperature probe
No (01)
No (0)
Yes (1)
-
CO-V
PH41
Enable return temperature probe
No (0)
No (0)
Yes (1)
-
CO-V
PH42
Enable CO
2
probe (0-5V)
No (0)
No (0)
Yes (1)
-
CO-V
PH43
Enable outside air temperature probe
No (0)
No (0)
Yes (1)
-
CO-V
PH44
CO
2
sensor probe
0: 0-20mA
1: 4-20mA
2: 0-5V
0-10V
(3)
0-20mA
(3)
0-10V (3)
-
CO-V
