PH99
Reset the factory parameters default
NO (0)
NO (0)
YES (1)
-
IS-D
Wait for the
NO (0)
value to be
read again
on reset
completion
PSd2
Installer level password (2)
0
-999
9999
-
IS
Level 3
MANUFACTURER MENU
CONFIGURATION PARAMETERS
After modification of these parameters it is recommended to remove and then re-apply the power supply to the board.
PG00
Unit type:
1=Compact
2=Complete
1
1
2
-
CO-G
PG01
Enabling bypass recuperator
Yes (1)
No (0)
Yes (1)
-
CO-G
PG02
Selection of type of device
for heating:
0: Disabled
1: Hot water coil only
2: Electric heater coil only DO
3: Electric heater coil only AO
Disabled
(0)
Disabled
(0)
Heaters
(3)
-
CO-G
PG03
Type of recovery heat exchanger by-pass
damper control:
0: Digital Control (DO7)
1: Analogue Control (AO3)
AO (1)
DO (0)
AO (1)
-
CO-G
PG04
Outside air damper enabling
No (0)
No (0)
Yes (1)
-
CO-G
PG05
Enabling of post-ventilation
No (0)
No (0)
Yes (1)
-
CO-G
PG06
Enabling of recovery heat exchanger anti-
freeze protection
Type 1
(1)
Not-active
(0)
Type 2 (2)
-
CO-G
PG08
Enabling of recovery heat exchanger
by-pass in summer
No (0)
No (0)
Yes (1)
CO-G
PG09
Activation of outside air damper limit switch
No (0)
No (0)
Yes (1)
CO-G
PG10
Type of fan
DO (0)
DO (0)
AO (1)
-
CO-G
If PF=1
PG10=1
PG11
Enabling of mixing room damper
No (0)
No (0)
Yes (1)
-
CO-G
PSd1
User level password (1)
0
-999
9999
-
CO-G
PSd2
Installer level password (2)
0
-999
9999
-
CO-G
PSd3
Manufacturer level password (3)
0
-999
9999
-
CO-G
FANS
PF06
Minimum time that must pass for the switch-
on/off of each individual step of the fans
3
0
999
Sec
CO-F
PF07
Temperature setpoint of the fans for anti-
freeze protection of the recovery heat
exchanger
2.0
PH01
PH02
°C
°F
CO-F
PF08
Differential for anti-freeze protection of
the recovery heat exchanger
2.0
0.0
0.0
20.0
36.0
°C
°F
CO-F
PF09
Minimum stand-by time before requesting
switch-off of a further fan step
5
1
99
Min
CO-F
