EVCO S.p.A.
EVF 300 series | Installer manual ver. 1.1 | Code 144F300E114
Page 57 of 62
19
TECHNICAL DATA
19.1
Technical data
Purpose of the command device:
operating command device.
Construction of the command device: built-in
electronic
device.
Case:
user interface
control module
board without cover fixed onto a
Plexiglas sheet.
board without cover.
Dimensions:
user interface
control module
110.0 x 250.0 x 36.7 mm (4.330 x
9.842 x 3.668 cm; L x H x D).
166.0 x 116.0 x 44.0 mm (6.535 x
4.566 x 4.399 cm; L x H x D).
Method of mounting the command device:
user interface
control module
rear of panel, with biadhesive tape.
on flat surface, with spacers.
Protection rating:
user interface
control module
IP65. IP00.
Connections:
user interface
control module
fixed screw terminal board (control
module).
removable screw terminal board (user
interface, power supply, inputs,
outputs and RS-485 port).
The maximum length of the analogue inputs and digital outputs connection
cables must be less than 10 m (32,808 ft).
The maximum length of the user interface-control module connection cables
must be less than 10 m (32,808 ft).
Operating temperature:
from 0 to 55 °C (from 32 to 131 °F).
Storage temperature:
from -10 to 70 °C (from -14 to 158 °F).
Humidity for use:
from 10% to 90 % relative humidity without condensate.
Command device pollution situation: 2.
Power:
user interface
control module
supplied from the control module.
115... 230 VAC (±15%), 50/60 Hz
(±3 Hz), 10 VA max.
