EVCO S.p.A. EVF 300 series | Installer manual ver. 1.1 | Code 144F300E114
Page 44 of 62
i15 0 1 - - - 1 1
effect caused by the activation of the electric absorption
protection input
0 = DISABLING STEAM INJECTION, SWITCH-OFF OF
STEAM GENERATOR, OF THE TOP OUTPUT AND
THE FLOOR OUTPUT - steam injection will be
disabled, the steam generator, the top output
and the floor output will be switched off; the
display will show the flashing “AL2” code and
the buzzer will be activated (until the input is
deactivated)
1 = “ENERGY SAVING” FUNCTION ACTIVATION - the
“energy saving” function will be activated (while
the input is deactivated)
i16 0 1 - - - 0 0
type of electric absorption protection input contact
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
PARAM. MIN. MAX. U.M. INP. 1 INP. 2 DIGITAL OUTPUTS
u1 0 1 - - - 0 0
utility managed by the digital output K4 (9)
0 = EXTRACTION HOOD - in this case, parameter i0
will have meaning
1 = MULTI-FUNCTION - in this case, the “VENT” key
will have meaning
u11 0 1 - - - 0 0
utility managed by the digital output K5 (9)
0 = TECHNICAL COMPARTMENT FAN - in this case,
parameter U12 will have meaning
1 = SWITCH-ON/OFF
u12 0 240 min 10 10
technical compartment fan switch-off delay from device
switch-off (only if u11 = 0)
PARAM. MIN. MAX. U.M. INP. 1 INP. 2 SERIAL NETWORK
LA 1 247 - - - 247 247 device address
Lb 0 3 - - - 2 2
baud rate
0 = 2,400 baud
1 = 4,800 baud
2 = 9,600 baud
3 = 19,200 baud
