P6
0
2
- - -
0
0
information shown in the top part of the "LOWER"
display when the device is on and when a cooking cycle
is in progress
0 = if CFG = 0, power distributed at the top
alternately to power distributed at the floor for
10 s
if CFG = 1, floor temperature
1 = if CFG = 0, power distributed at the top
if CFG = 1, floor set-point
2 = if CFG = 0, power distributed at the floor
if CFG = 1, reserved
P7 0
99/210
°C/°F
(1)
0 0
temperature above which the use temperature alarm is
activated (code “Ht”; relative to the control module use
temperature, i.e. “control module use temperature +
P7”)
0 = no alarm
PARAM.
MIN.
MAX.
U.M.
INP. 1
INP. 2
MAIN REGULATOR
r0 1 99
°C/°F
(1)
5 5
if CFG = 0, work set-point differential (of SP)
if CFG = 1, top set-point differential (of SP1)
r1 0 r2
°C/°F
(1)
50 50
if CFG = 0, minimum work set-point
if CFG = 1, minimum top set-point
r2 r1 999
°C/°F
(1)
350
350
if CFG = 0, maximum work set-point
if CFG = 1, maximum top set-point
r6
1
99
°C/°F (1)
not dis.
5
floor set-point differential (of SP2)
r7 0 r8
°C/°F
(1)
not
dis.
50
minimum
floor
set-point
r8
r7
999
°C/°F (1)
not dis.
350
Maximum floor set-point
r12
0
1
- - -
0
0
enabling the "weekly programmed switch-on" function
1 = YES
r13 0 240 min 240
240
duration of a power supply cut-off that occurs during the
cooking timer count, such to cause the interruption of
the cooking cycle (3)
PARAM.
MIN.
MAX.
U.M.
INP. 1
INP. 2
STEAM INJECTION
SPS
0
999
°C/°F (1)
100
100
steam set-point; see also t3 (only if P4 = 2)
