i0 0 2 - - - 2 2
effect caused by the activation of the door micro switch
input
0 = no effect
1 = EXTRACTION HOOD SWITCH-ON - the extraction
hood will be switched on (only if
u1 = 0, until the input is deactivated)
2 = SWITCH-ON OF THE EXTRACTION HOOD,
SWITCH-OFF OF THE TOP OUTPUT AND FLOOR
OUTPUT AND DISABLING OF STEAM INJECTION
- the extraction hood will be switched on (only if
u1 = 0); the top output and the floor output will
be switched off and the steam injection will be
disabled (until the input will be deactivated)
i1 0 1 - - - 0 0
type of door micro switch input contact
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i5 0 1 - - - 1 1
effect caused by the activation of the multifunction input
0 = no effect
1 = CONSENT FOR STEAM INJECTION - steam
injection will be allowed (until the input s
deactivated, only if
P4 = 1)
1 = DEVICE SWITCH-OFF - the device will be
switched off (while the input is deactivated)
i6 0 1 - - - 0 0
type of multifunction input contact
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i11 0 1 - - - 0 0
type of circuit breaker protection input contact
0 = normally open (input active with closed contact)
1 = normally closed (input active with open contact)
i12 0 120 s 10 10
input circuit breaker protection alarm signal delay
(“AL1” code)
