PortVision DX User Guide
Loading Configuration Files
If you have previously saved a Comtrol Ethernet attached product configuration file, you can load
that configuration and apply it to a selected device or devices.
•
Main screen (all Comtrol Ethernet attached products)
•
Software Settings tab (DeviceMaster, DeviceMaster UP, and IO-Link Master)
Note: If this is a DeviceMaster configuration file with SocketServer v8.04 or previous and
you want to load it on a DeviceMaster running SocketServer v9.00 or higher, you
must convert the configuration file. See
Converting DeviceMaster Configuration
Files .
Main Screen
Use this procedure to load a configuration file using the Main screen to one or more devices.
1. From the Device List pane on the Main screen, use one of the following methods:
•
Highlight the Comtrol Ethernet attached product, click the Load button
•
Right-click the Comtrol Ethernet attached product, click Configuration, and then
Load.
•
Highlight the Comtrol Ethernet attached product, click the Manage menu, click
Configuration, and then Load.
2. Click Yes to the warning that it will take 25 seconds per device and that it may also
reboot the devices.
3. Browse to the location of the configuration file, click the file name and then Open.
Configuration Files - DeviceMaster
137
