DeviceMaster LT User Guide: 2000586 Rev. B Hardware Specifications - 109
Hardware Specifications
Locating DeviceMaster LT Specifications
Specifications can be found on the Comtrol web site.
External Power Supply Specifications
This subsection discusses information that you may need if you wish to use your
own external power supplies.
This table provides specifications for the power
supply shipped with the DeviceMaster LT.
This table provides the specifications, if you
intend on using your own power.
Comtrol Power Supply: 5-30VDC
Input line frequency
Input line voltage
Output voltage
Output current
43-63 Hz
90-260 VAC
5-30VDC
275 mA @ 24VDC
External Power Supply: 5-30VDC
Output voltage†
Current†
Power
5-30VDC
200 mA (Min) @ 24VDC
4.5 W
† Any power supply that meets current
consumption, voltage, power, and connector
pinouts requirements can be used.
Earth Gnd
Return
Positive
5-30VDC
+
-
Wire gauge:
AWG 12-22
Screw Terminal Connector
